Rancho RS994310 – 06-10 Hummer H3 Rear RS9000XL Shock (Available MAY 2026, NO BACKORDERS)

Description

Rancho RS994310 – 06-10 Hummer H3 Rear RS9000XL Shock (Available MAY 2026, NO BACKORDERS)

Rancho RS9000XL RS994310 Suspension Shock Absorber

With nine levels of adjustment, Rancho® RS9000®XL shocks provide premium control and performance. An easy-to-adjust knob enables customized damping and firmness for both on-road and off-road versatility. Now in its fourth generation, this cutting-edge shock boasts integrated bottom mounts for enhanced strength and a dual component 2K paint finish for superior chip resistance. Tougher and better-looking than ever, the RS9000XL sets a new standard in durability and design.

• NINE LEVELS OF PERFORMANCE — Nine-position easy-to-adjust knob allows customized damping control and firmness for on-road and off-road flexibility
• DESIGNED FOR HARDWORKING VEHICLES — Ideal for stock or lifted trucks, SUVs and Jeeps that tow, haul or go off road
• REDUCES FADE — Nitrogen gas pressurized to 45 or 60 PSI to minimize air-to-oil mixture and reduce damping performance fade and foaming
• HANDLES EXTREME TEMPERATURE CHANGES — Up to 2.38-in. tri-tube body (application specific) filled with all-weather fluid allows for cooler operation, increased vehicle control and ability to withstand internal temperatures of -40 to 248°F
• SMOOTH PERFORMANCE — Polyurethane rebound bumper and bushings and graphite-filled fluon-banded piston help absorb ride harshness and enhance responsiveness to changing road conditions for an overall smoother ride
• BUILT TO LAST — Low-friction, self-lubricating seal retains gas and oil for quicker rebound and smoother compression while the long-lasting premium liquid metallic finish and polyvinyl protective boot ensures longer life
• BOLD NEW LOOK — Sleek dual component 2K paint finish not only looks good but delivers superior chip resistance
• BUY WITH CONFIDENCE — Comes with Rancho’s Limited Lifetime Warranty

Compressed Length: 17.22Compressed Length: 437.4Extended Length: 700.5Extended Length: 27.58Travel Length: 10.36Travel Length: 263.1Shock Stroke: 263.1Shock Stroke: 10.36Lower Mount Type: Loop Bushing and Sleeve Mount – 9/16″ Sleeve ID X 1.5/8″ Sleeve OALLower Mount Code: LS47Upper Mount Type: Cross Pin Mount – Closed Ended, 3/8″ Hole ID (Both Ends) X 2.3/4″ Pin Length (Hole Center to Center)Upper Mount Code: XP11Shock Absorber Rod End Measuring Point: Center of LoopShock Absorber Body End Measuring Point: Center of Cross PinGas Charged: YesMounting Hardware Included: NoParts Pack(s): NoneBody Diameter: 2.18Body Diameter: 55.4Cylinder Outside Diameter: 55.4Cylinder Outside Diameter: 2.18Body Material: SteelCylinder Material: SteelBody Color: SilverCylinder Color: SilverColor: SilverFinish: PaintedCylinder Finish: PaintedBoot Included: YesDust Shield Included: YesDust Shield Diameter: 2.99Dust Shield Diameter: 75.946Dust Shield Material: RubberDust Shield Color: RedRod Diameter: 15.8Rod Diameter: 0.6220472440944882Shaft Material: ChromedShock Absorber Bore Size: 32Shock Absorber Bore Size: 1.2598425196850394Includes Bump Stop: NoInternal Rebound Bumper: YesInternal Rebound Spring: NoHydraulic Lockout: NoInternal Construction Type: Tri TubeGrade Type: PerformanceType: TelescopicAdjustable Damping: YesActive or Passive Suspension: PassiveAdjustable Compression: YesAdjustable Rebound: YesDamping Adjustment Type: ManualValving Type: ProgressiveSelf-Leveling: NoAdjustable Ride Height: NoMaximum Ride Height Lowering Distance: 0Maximum Ride Height Raising Distance: 0Air Adjustable: NoAir Ride Suspension: NoBladder(s) Included: NoBladder Sleeve(s) Included: NoBladder Heavy Duty Crimping Rings Included: NoNew Or Remanufactured: NewCoil Over Springs Included: NoBearing Plate Included: NoSpring Included: NoCoil Spring Insulator(s) Included: NoSpring Isolators Included: NoSpring Seat Included: NoRemote Reservoir: NoStrut Mount Insulator(s) Included: No
