Mishimoto MMINT-Q50-16 – 2016+ Infiniti Q50/60 3.0T Performance Air-To-Water Intercooler Kit

Description

Mishimoto MMINT-Q50-16 – 2016+ Infiniti Q50/60 3.0T Performance Air-To-Water Intercooler Kit

Performance Air-To-Water Intercooler Kit, fits Infiniti Q50/Q60 3.0T 2016-2024

Complete intercooler kit engineered to reduce intake air temperatures for increased power and efficiency. Includes high-quality components for optimal airflow, improved throttle response, and a precise, easy installation.

That’s why Mishimoto has developed our performance air-to-water intercoolers for the 2016-2024 Q50/Q60 3.0T. Our intercoolers feature a 49.8-percent increase in core volume over the stock intercoolers for improved heat transfer and maximum performance. That increase in core volume, combined with optimized tubes and fins, also allows our intercoolers to be over 51-percent less restrictive than stock. That means your turbos don’t have to work as hard, and the boost pressure they generate isn’t wasted shoving air through a restrictive intercooler. All those improvements result in dyno-proven charge air temperatures that are up to 23-degrees cooler than stock. Colder intake charge temps mean your VR30 can make the most of every drop of fuel, and we were able to produce power gains of up to 8 HP and 12 lb.-ft of torque without a retune. We also know that high boost pressures require strong components, which is why we constructed our intercoolers with cast aluminum end tanks. This design eliminates potential leak points and stress concentrations that welded tanks may suffer from. The included ancillary hoses and couplers ensure coolant and air flow reliably through the intercoolers, and the included engine cover spacers let you keep your extra cooling hidden for a stealth approach. Like all Mishimoto products, these performance intercoolers for the 2016-2024 Q50/Q60 3.0T are backed by our Mishimoto Lifetime Warranty.

• Max power gains of up to 13.82 HP and 16.87 lb-ft of torque
• 23F cooler charge air temperature than stock
• 51.4-percent less restrictive than stock intercoolers

Maximum Boost Pressure: 0Maximum Horsepower: 900Pipe Color: SilverPipe Finish: Powder CoatedPipe Material: AluminumUniversal Or Specific Fit: SpecificTechSpec Applications: 2016-2024 Infiniti Q50 3.0T–2016-2022 Infiniti Q60 3.0TTechSpec Engine Codes: VR30DDTTTechSpec Chassis Codes: Q50–Q60TechSpec Maximum Recommended Boost Pressure (PSI): N/ATechSpec Maximum Recommended Horsepower: 900TechSpec Overall Length (in): 11.65TechSpec Overall Height (in): 5.68TechSpec Overall Width (in): 9.23TechSpec Core Type: Bar-and-PlateTechSpec Core Thickness (in): N/ATechSpec Core Length (in): 4.64TechSpec Core Height (in): 3.98TechSpec Inlet (in): 1.97TechSpec Outlet (in): 2.56TechSpec Weight (lbs): 8.59TechSpec Note: Does not fit with aftermarket blow off valvesTechSpec Includes: (2) Mishimoto Performance Intercoolers–(6) Intercooler Coolant Hoses–(1) Coolant Y-Pipe–(2) Intercooler Mounting Brackets–(3) DuraCore Intercooler Couplers–(20) Worm Gear Clamps–(2) Engine Cover Spacers–(1) Mishimoto Catch Can Relocation Kit–Mounting Hardware–Mishimoto Lifetime WarrantyTechSpec Installation Notes: N/ATechSpec Pipe Shape: N/ATechSpec Pipe Diameter: N/ATechSpec Pipe Length: N/ATechSpec Centerline Radius: N/ASellingPoint01: Direct fit for the 2016-2024 Infiniti Q50/Q60 3.0TSellingPoint02: Max power gains of up to 13.82 HP and 16.87 lb-ft of torqueSellingPoint03: 23F cooler charge air temperature than stockSellingPoint04: 51.4-percent less restrictive than stock intercoolersSellingPoint05: 49.8-percent increase in core volume over stock intercoolersSellingPoint06: Maintains air pressure drop to within 1 PSI of stockSellingPoint07: Bar-and-plate core for efficient heat transfer and heat soak resistanceSellingPoint08: Cast-aluminum end tanks withstand high boost levelsSellingPoint09: Fits with stock engine cover using included spacersSellingPoint10: Included bracket allows use with Mishimoto catch canSellingPoint11: Includes direct-fit ancillary hoses and couplersSellingPoint12: Anti-abrasion hose sleeve prevents damage and leaksSellingPoint13: Durable micro-wrinkle black powder coast resists corrosionSellingPoint14: Patent No. US D1,073,738SellingPoint15: Mishimoto Lifetime WarrantyInstall Difficulty: 3OptionLabel: N/ACold Side Pipe Inside Diameter: 2.56Core Thickness: 0Core Length: 4.64Core Height: 3.98Core Color: SilverCore Construction: Bar-and-PlateCore Material: AluminumCoupler Color: BlackCoupler Material: SiliconeEnd Tank Construction: CastEnd Tank Material: AluminumGrade Type: PerformanceHose Clamps Included: YesHot Side Pipe Inside Diameter: 1.97Inlet Diameter: 1.97Outlet Diameter: 2.56Intercooler Type: Air-to-Air
