Mahle Motorsport 197832209 – Mahle MS BMW N54 B30 3.0L 84.00mm x 31.7mm CH 17.2cc 314g 10.2CR Pistons (Set of 6)

Description

Mahle Motorsport 197832209 – Mahle MS BMW N54 B30 3.0L 84.00mm x 31.7mm CH 17.2cc 314g 10.2CR Pistons (Set of 6)

Piston (set) – BMW N54 B30 3.0L

84.00mm x 31.7mm CH, 89.6mm stroke,145.05mm rod,22mm pin,-17.2cc,314g,10.2CR, 2618

Pin Diameter: 22.0mmUCR Coating: Gas NitridedOCR Thickness: 2.8mmOCR Tension: StandardOCR Material: Chrome plated stainless steelLCR Thickness: 1.2mmLCR Material: Cast IronLCR Coating: PhosphateFile Fit: NCrown Volume: -17.2ccClips Included: YClip Style: Round WireUCR Thickness: 1.0mmUCR Material: Stainless SteelPin Length: 48.0mmRings Included: YPiston Style: Dish, w/ 4 valve reliefsPiston Ring Thickness: 1.0mm, 1.2mm, 2.8mmPiston Material: Forged, 2618Piston Mass: 314gPins Included: YPin Wall Thickness: 0.197Pin Style: FloatingPin Material: SteelPin Mass: 93gPackage Quantity: Sold as a set of 6
