Firestone 9277 – Air Tank 20 Gallon 12in. x 44in. (6) 1/2in. NPT Ports 150 PSI Max – Black (WR1760)

Description

Firestone 9277 – Air Tank 20 Gallon 12in. x 44in. (6) 1/2in. NPT Ports 150 PSI Max – Black (WR1760)

Air Tank 20 Gal 7 Ports

Air Tank; 20 Gallon; 12 in. Dia.; 44 in. Length; Six 1/2 in. NPT Ports; 1/4 in. NPT Port; 150 PSI Max; Black;

This Firestone Air Tank provides a source of compressed air for an air spring system. Tank has 20-Gallon capacity, (6) 1/2″ NPT Ports and (1) 1/4 port. Tank is enamel coated, tested to be SAE J10 compliant and capable of 150 psi. Features: Provides compressed air source for an air helper spring system Allows for faster inflation of air springs Holds 20 Gallons of compressed air Includes (6) 1/2 in., and (1) 1/4 NPT Ports Steel Tank with brass fittings Resists corrosion with internal and external enamel coating Is SAE J10 compliant Operates at up to 150 psi of maximum pressure Specs: Tank dimensions: 44 in. long x 12 in. diameter Tank capacity: 19 Gallons Inflation Ports: 1/2 in. and 1/4 in. NPT PSI: Maximum of 150 2-Year limited warranty

• Manufactured To SAE J10 Specifications
• Pressure Tested To Twice The Working Pressure
• Baked Black Enamel On Inside And Outside
• Prevents Corrosion

Add-On: Not ApplicableSize: 12 gal.
