Bilstein 33-366883 – Shock Absorbers

Description

Bilstein 33-366883 – Shock Absorbers

AS2-R Series – Suspension Shock Absorber

46mm Monotube Suspension Shock Absorber

Bilstein AS2-R Series Suspension Shock Absorbers are designed for motorsports applications and provides premium performance through superior tuning and modular design. The package features an aluminum-bodied remote reservoir with tunable base valve technology and several adjustment options mated to Bilstein’s AS2 Series aluminum modular shock. The lightweight threaded body shock can be used with or without coilover hardware. Pistons, piston bands and heims are sold separately to allow the greatest flexibility in upgrade combinations. The AS2-R Series Suspension Shock Absorbers offer racers a versatile damper that maximizes suspension travel and gives an endless range of options for tuning and upgradeability.

• Championship-winning tuning options
• All dampers feature 46mm aluminum monotube designs for light weight and hard anodized for durability
• Low friction rod guides for minimum rod drag

Extended Length (IN): 25.92Spring Seat Included: YesCollapsed Length (IN): 16.98Adjustable Damping: Non-AdjustableExtended Length (mm): 658.3Internal Design: MonotubeUpper Mount Type: 1/2in HeimBody Design: Threaded Body Screw Top (Coilover)PartType: Shocks / StrutsSeries: AS2-R SeriesBody Material: AluminumCollapsed Length (mm): 431.3Valving Identifier: LRB BVT BIL0Boot Included: NoFinish: Clear AnodizedShaft Diameter: 14mmPiston Diameter: 46mmLower Mount Type: 1/2in HeimSpring Hardware: B4-MKT-0010A00Segment: MotorsportsSpring Hardware 2: E4-MSG-0083A00Piston Type: Two Port Linear
