Bilstein 33-304281 – Shock Absorbers

Description

Bilstein 33-304281 – Shock Absorbers

Shock – SNS2 Series – Monotube – 15.12 in Compressed – 23.9 in Extended – 1.81 in OD – C8-R2 Valve – Steel – Zinc Plated – Each

46mm Monotube Shock Absorber

Bilstein SNS2 Series shock absorbers feature a steel, smooth body design utilizing the 46mm monotube technology (piston and piston band sold separately) designed for motorsports applications. These shock absorbers feature a steel body cap and a Schrader valve or fill plug. They are upgradeable to adjustable shafts and can be converted to a coilover (kit sold separately). SNS2 Series shock absorbers are ideal for racers whose sanctioning rules require an all steel construction with rebuild capability.

• Plated steel body for durability and superior heat dissipation
• 46mm piston design for maximum damping control
• Standard 1/2” graphite heims

Adjustable Damping: Non-AdjustableSpring Seat Included: NoCollapsed Length (IN): 15.12Body Design: Smooth Body Screw Top (Non-coilover)Extended Length (MM): 607.0Internal Design: MonotubeUpper Mount Type: 1/2in HeimStroke/Travel Length (IN): 8.78PartType: Shocks / StrutsSeries: SNS2 SeriesBody Material: SteelStroke/Travel Length (mm): 223.0Collapsed Length (MM): 384.0Boot Included: NoFinish: Zinc PlatedShaft Diameter: 14mmPiston Diameter: 46mmLower Mount Type: 1/2in HeimSegment: MotorsportsSpring Hardware: B4-BOA-0000117Piston Type: 8/2 (comp/reb)Extended Length (IN): 23.90
